Cylindrical models with slanted cuts

The DigiSkills 1 learning project includes various model sets, from the simple geometric model to models with real function. The geometric models support the learning process in the introduction to engineering drawing: from the concrete body to the more abstract representation of the three views of a engineering drawing.

• models providing an introduction to engineering drawing
• set of 18 cylindrical models, made from aluminium
• cylindrical models with cuts parallel and oblique to the spatial axes
• finely graduated degrees of difficulty within the model series
• all models clearly laid out in a storage system
• multiple storage systems can be stacked on top of each other
• precision manufacture of the models enables measurement exercises
• lesson-supporting instructional material
• multimedia instructional materials: PDF, DXF files, STEP files
• online access to the Media Center
• part of the DigiSkills: vertical teaching of digital skills in complex learning projects
