DC Permanent Magnet Machine 370W

DC Motor and Generator operation, suitable for permanent magnet excited connection.

Nominal Power :

• 370W

Nominal Voltage :

• 0 ~ 220VDC

Nominal Current :

• 3.0 A

Nominal Speed :

• 1500 rpm

Winding Poles :

• 4

Terminals :

• 4mm Safety Socket

Coupling :

• Optional (Alignment Needed For Coupling To Generator Brake Unit)

Base Plate :

• Attachable To Break Load Unit / Generator Unit

Manual :

• Instructional & Experimental Manual Provided

Typical Experiments :

• DC Motor Starting
• Winding Resistance Measurement
• Load Test
• Speed Control
• Nominal Load and Over Load Test
• Magnetic Characteristics
• Electromechanical Characteristics
• Efficiency Determination
