DC to DC Converter Trainer Buck Boost and Buck Boost Converters

The DC to DC Converter Trainer Buck Boost and Buck Boost Converters is designed for practical study of DC-DC power conversion techniques. It provides individual circuits for buck, boost, and buck-boost converter configurations, allowing students to understand voltage conversion, switching operation, and power electronic control through hands-on experimentation. The trainer includes digital meters, a MOSFET switching device, PWM pulse generation, and frequency control for practical circuit studies. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Digital Meters:

• Voltmeter: 200 V DC.
• Ammeter: 20 A DC.

Power Supplies:

• +15 V / 150 mA.
• Isolated supply: 0–26 V AC at 2 A.
• Mains operated: 230 V, 50 Hz ±10%.

Components Mounted on Panel:

• MOSFET IRF540.
• PWM pulse generator circuit.
• Frequency control through potentiometer.

Load:

• Rheostat as resistive load.

• Individual circuit for buck converter.
• Individual circuit for boost converter.
• Individual circuit for buck-boost converter.
• Protective cover.
• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Overload protection through circuit breaker.
• Fuse protection against short-circuit conditions.
• Instruction manual.
• Connections through 4 mm and 2 mm coloured sockets.
• 4 mm and 2 mm patch cords.
• Housed in a metal cabinet.
• Trainer size: 15 × 11 inches.
