DEFLECTIONS OF TRUSSES

A set of eighteen truss members with lengths based on the 3:4:5 triangle enables at least three different three-bay cantilever trusses to be built with true pin joints. Two springings fix to the vertical side of a universal frame and stand (sold separately). Truss joint deflections are measured using a movable dial gauge mounted on a sub-frame attached to each springing, ensuring deflections are truly relative to the truss springings. Learn about DEFLECTIONS OF TRUSSES equipment for optimal educational outcomes.. Calibrated weights and a hanger are supplied for loading.

• Truss A: 720 (L) × 180 (H) mm
• Truss B: 540 (L) × 240 (H) mm
• Truss C: 720 (L) mm × 20.5° top member inclination
• Member section: 25 (H) × 10 (W) mm
• Digital Dial Gauge: 12.7 mm travel; 0.01 mm resolution
• Weights set: 5 × 20 N, 1 × 50 N
