Deleterious Particles Determination Apparatus for Oil Fuel and Petroleum Testing Instruments

The Grease Contamination Tester detects and estimates deleterious particle contamination in lubricating greases, other semi-solids, and heavy liquids. Grease fillers can be tested for abrasive contaminants by first mixing them into petrolatum or grease known to be free of harmful particles. The instrument rotates a plastic test plate through 30° against a stationary plate while applying a pressure of 200 psi. It includes a main body, test plate holders, loading screw, calibrated spring with scale for applying the test load, and a removable cap assembly with a milled slot and handle for rotating the test plates. The apparatus is constructed of stainless steel. Plastic test plates must be ordered separately. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricant contamination testing applications.

Testing Principle:

• Plastic test plate rotates 30° against a stationary plate
• Applied pressure: 200 psi
• Detects and estimates deleterious particle contamination

Construction and Features:

• Stainless steel construction
• Main body
• Test plate holders
• Loading screw
• Calibrated spring with load scale
• Removable cap assembly with milled slot and handle
• Plastic test plates available separately

Net Weight:

• 5 lbs (2.3 kg)
