Demo Box Basic Equipment Optical Bench Physics School Science STEM Kit

Function and Applications:

• Designed for demonstrating the fundamental laws of light

• Contains all components required for experiments on:

  • Propagation of light
  • Reflection of light
  • Refraction of light
  • Dispersion of white light into component colours

• Also supports experiments illustrating:

  • Structure and function of the human eye
  • Common optical instruments

• With the demo set “Basic Equipment Optical Bench,” all major optics topics taught at high school level can be demonstrated

• Includes:

  • Storage plan for organised arrangement of components
  • Handy instructional handout

• Experiments 1–20 can be performed with this set

• Experiments 21–27 require the additional Wave Optics extension set

Equipment and Technical Data:

Optical lamp with halogen lamp 12 V / 50 W

• Bright light source suitable for:
  • Optical bench experiments
  • Projection experiments

• Halogen lamp lifetime: approx. 2,000 hours
• Condenser focal length: 38.5 mm
• Condenser diameter: 50 mm
• Lamp base: GY 6.35
• Housing dimensions: 240 × 110 × 100 mm
• Tube diameter: 10 mm

• Built-in reflection mirror
• Aspherical condenser
• Adjustable and rotatable positioning drive
• Lateral and axial lamp adjustment
• 4 mm connection sockets
• Fork holder on rod for angled mounting
