Demo unit, gas burner

The unit demonstrates the basic functioning of an original gas burner and its typical behaviour in case of faults. Standard industrial components are used. All operating states of the burner are simulated, allowing this demo unit to be operated without gas and flames. Learn about Demo unit, gas burner for educational labs for optimal educational outcomes.. The unit is therefore totally non-hazardous and has no gas or waste gas lines. On the front panel is a graphical representation of the controller unit connection. Learn about Demo unit, gas burner specifications for optimal educational outcomes.. Important electrical monitoring points on the burner are accessible for fault analysis using lab jacks and bridges on the front panel. Faults can thus be checked either during operation under voltage or with no voltage as an isolated component. Learn about Demo unit, gas burner equipment for optimal educational outcomes..

• simulation model of a forced air gas burner and all burner operating states
• fault simulation: 9 fault buttons in lockable box
• additional actual system components: flame safeguard, gas pressure and air pressure control devices, ignition transformer, thermostat, safety temperature limiter, gas solenoid valves, fan motor, emergency switch heating system
• important electrical monitoring points on burner accessible via lab jacks and measuring bridge connectors for fault analysis
