Demonstration Infiltration Unit

The Demonstration Infiltration Unit, for the comparative study of infiltration processes in the laboratory, which are essential for the study of any form of irrigation.

ATENG 11645 — Demonstration Infiltration Unit

Bench-top unit.

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

Diagram in the front panel with distribution of the elements similar to the real one.

• Three transparent graduated cylinders:
• External diameter: 100 mm.
• Height: 600 mm.
  With a permeable perforated plate at the bottom, where a filter to disable the soil introduced
  to be swept by the water is placed.
• Tank to collect the water and the smaller soil particles under study:
  ATENG 11645 detail
• Capacity: 25 l.
  It has a drain valve.
