Design of Electronic Balance Lab Experiment

This apparatus is designed for studying strain gauge sensors and their applications in force and weight measurement. It enables testing of sensor characteristics, determination of sensitivity, and the design, calibration, and evaluation of an electronic weighing system. Physics Lab Experiments from Atico Exports.

Measuring Range :

• 0 to 1 kg

Tray Diameter :

• 120 mm

Voltage Range :

• 1.5 to 5 V

Digital Display :

• 3½-digit digital display

Sensitivity :

• Adjustable

Zero Adjustment Function :

• Provided

Total Weight :

• 1 kg

Test Materials :

• Alloy
• Aluminum
• Iron
• Wood

Digital Multimeter :

• 4½-digit digital multimeter

Voltage Range :

• 200 mV

Resistance Range :

• 200 mΩ

• Suitable for sensor calibration, sensitivity analysis, and electronic weighing applications.
• Provides practical understanding of strain gauge measurement techniques and bridge circuits.
