Determination of Plancks Constant from the LED

Study of Planck’s Constant by Means of LED setup is designed for the experimental determination and study of Planck’s Constant using the current-voltage (I-V) characteristics of a Light Emitting Diode (LED).

The setup allows the study of the dependence of current on temperature at a constant applied voltage. It also provides facilities to draw the I-V characteristics of an LED for the determination of the material constant using a variable voltage source and current meter.

Physics Lab Experiments Setup from Atico Exports.

Experimental Facilities :

Current Meter :

• Highly Stable Current Source
• 3-Digit Display

Current Range :

• 0 to 2000 µA / 20 mA

Oven :

• Small Temperature-Controlled Oven
• Built-in RTD Sensor

Temperature Range :

• Ambient to 80°C

Temperature Display :

• Digital Display

Stability :

• High Stability

Variable Voltage Source :

• Range: 0 to 2.75 V
• High-Stability Voltage Source
• 3-Digit Display

Material Constant :

• Variable Voltage Source and Current Meter Provided for Plotting the I-V Characteristics of LED
• 3-Digit Display for Measurement

LED Wavelength :

• Wavelength of Light Emitted by LED is Taken from the LED Datasheet

Technical Specifications :

Packaging Type :

• Corrugated Boxes

Material :

• Stainless Steel

Type :

• Digital

Power Supply :

• AC Mains

Usage / Application :

• Laboratory
