Determination of Specific Heat of Solids

The Specific Heat Capacity Experiment is designed to determine the specific heat capacity of different solid materials using the method of mixtures. In this experiment, heated samples are transferred into a known quantity of water contained in a Dewar calorimeter. By measuring the initial and final temperatures and applying the principle of heat conservation, the specific heat capacity of the sample material can be calculated. The apparatus provides an effective demonstration of heat transfer and calorimetry principles. Manufactured by Atico Export India.

Principle

The experiment is based on the principle of conservation of energy. A solid sample is heated to the temperature of steam and then transferred into water contained in a Dewar calorimeter. Heat released by the hot sample is equal to the heat absorbed by the water until thermal equilibrium is reached. Since the specific heat capacity of water is known, the specific heat capacity of the solid sample can be determined from the measured masses and temperatures.

Objectives

• Determine the specific heat capacity of different solid materials.
• Study heat transfer between solids and liquids.
• Verify the principle of conservation of energy.
• Understand the method of mixtures in calorimetry.
• Compare the specific heat capacities of different materials.

System Components

Cover for Dewar Vessel :

• Quantity: 1

Dewar Vessel Calorimeter :

• Capacity: 250 ml
• Quantity: 1

Thermometer :

• Range: -10°C to +110°C
• Resolution: 0.2 K
• Quantity: 1

Heating Apparatus :

• Quantity: 1

Copper Shot :

• 200 g
• Quantity: 1

Glass Shot :

• 100 g
• Quantity: 1

Lead Shot :

• 200 g
• Quantity: 1

Single-Pan Suspension Balance :

• Quantity: 1

Steam Generator :

• Quantity: 1

Beaker :

• Capacity: 400 ml
• Quantity: 1

Silicone Tubing :

• Diameter: 7 mm
• Length: 1 m
• Quantity: 1

V-Shaped Stand Base :

• Quantity: 1

Stand Rod :

• Length: 47 cm
• Diameter: 12 mm
• Quantity: 1

Multi Clamp :

• Quantity: 1

Universal Clamp :

• Capacity: 0 to 80 mm
• Quantity: 1

Heat Protective Gloves :

• Quantity: 1

Dewar Calorimeter :

• Minimizes heat loss during the experiment for improved accuracy.

Steam Heating Method :

• Heats samples uniformly to steam temperature before testing.

Multiple Sample Materials :

• Includes copper, glass, and lead samples for comparative analysis.

Accurate Temperature Measurement :

• High-resolution thermometer ensures precise temperature readings.

Complete Experimental Setup :

• Provides all essential components required for calorimetry experiments.
