Determining the Capacitance of a Plate Capacitor Measuring the Charge with the I Measuring Amplifier D

The Parallel Plate Capacitor Experiment is designed to measure the capacitance of a parallel plate capacitor as a function of plate separation with high accuracy. The apparatus features a precision parallel plate capacitor with continuously adjustable plate spacing, allowing students to verify the theoretical relationship between capacitance and plate distance. It provides a practical demonstration of electrostatic principles and capacitor characteristics. Manufactured by Atico Export India.

Principle

The capacitance of a parallel plate capacitor is inversely proportional to the distance between its plates and directly proportional to the plate area. By continuously varying the plate separation and measuring the corresponding capacitance, the theoretical relationship between capacitance and plate spacing can be experimentally verified.

Objectives

• Measure the capacitance of a parallel plate capacitor.
• Study the effect of plate separation on capacitance.
• Verify the theoretical relationship between capacitance and plate spacing.
• Compare experimental results with theoretical values.
• Understand the operating principles of parallel plate capacitors.

System Components

Parallel Plate Capacitor :

• Quantity: 1

Tube Power Supply :

• Output: 0 to 500 V
• Quantity: 1

Two-Way Switch :

• Quantity: 1

Current Measuring Amplifier :

• Quantity: 1

Analog Multimeter :

• Quantity: 2

Measuring Resistor :

• Resistance: 100 MΩ
• Quantity: 1

Connecting Lead :

• Current Rating: 19 A
• Length: 50 cm
• Color: Red
• Quantity: 1

Connecting Leads :

• Current Rating: 19 A
• Length: 50 cm
• Red/Blue Pair
• Quantity: 3

Connecting Leads :

• Current Rating: 19 A
• Length: 100 cm
• Red/Blue Pair
• Quantity: 1

Precision Parallel Plate Capacitor :

• Designed for accurate capacitance measurements.

Large Diameter Plates :

• Plate Radius: 13 cm

Continuously Adjustable Plate Spacing :

• Adjustable Range: 0 to 70 mm

High Measurement Accuracy :

• Suitable for precise verification of capacitance characteristics.

High Voltage Operation :

• Powered by a 0 to 500 V tube power supply.

Educational Design :

• Ideal for electrostatics and capacitor experiments.
