Dielectric Constant Measurement by Deasuty Bridge for Physics Lab Experiments Complete Setup

Dielectric Constant Measurement by Deasuty Bridge for Physics Lab Experiments Complete Setup is designed to measure the unknown value of capacitance. The instrument consists of built-in components housed in an ABS plastic case for convenient operation and clear understanding of the experiment.

Physics Lab Experiments Setup from Atico Exports.

AC Source :

• Sine Wave Signal
• Frequency: 1 kHz
• AC Switch Indicating Lamp Provided on the Bakelite Board
• Two Sockets Provided for AC Signal Output

Detector :

• Built-in Null Detector
• Digital Display
• Designed for Detecting Small AC Output Signals

Circuit Diagram :

• Circuit Layout Clearly Printed on the Board
• Spread-Out Arrangement for Convenient Operation and Easy Understanding
• 4 mm Sockets Provided for Making Connections

Features :

R2 Resistance :

• Three-Decade Resistance Dials
• 10 × 1000 Ω
• 10 × 100 Ω
• 10 × 10 Ω

R1 Resistance :

• Single-Decade Resistance Dial
• 10 × 100 Ω

C1 Capacitor :

• Unknown Capacitor

C2 Capacitors :

• Two Fixed Standard Capacitors
• 0.01 µF
• 0.1 µF
• Loss-Free Type
