Digital Application

This digital application modules trainer is designed to provide further and more extensive studies about some important digital circuits
The trainer consists of a number of individual modules that can be used with the Digital electronics Lab Base Station.

The students are also expected to take main electronic instrument measurements in order to understand and to study the circuit electrical characteristics and behavior

• Each application circuit module is printed on a special design PCB that shows the circuit layout on top of the PCB (component side)
• The circuit path is able to be observed from the bottom side of the PCB (solder side)
• The circuit module is placed on a digital base station that facilitates other requirements for the module such as digital data switches, digital logic indicator, pulse switches, clock generator, seven segment displays etc.
