Digital Evaporation Loss Test Bath

The Evaporation Loss Test Bath is a high-temperature semi-automatic instrument designed for determining the evaporation loss of lubricating oils and petroleum-based products. It features a built-in self-lifting mechanism that automatically opens and closes the pump according to the testing process, ensuring efficient and reliable operation. The unit is equipped with a touch screen LCD for convenient parameter monitoring and complies with ASTM D5800 standard test methods for accurate evaporation loss determination. Manufactured by Atico Export India.

• Petroleum laboratories
• Lubricating oil testing
• Oil and grease analysis
• Quality control laboratories
• Research and development laboratories
• Chemical laboratories
• High-temperature evaporation loss testing

Temperature Control Range :

• 250°C ± 0.5°C

Temperature Control Method :

• Touch Screen LCD

Pressure Regulator :

• Precision Needle Valve

Pressure Display :

• Inclined Manometer

Compliance :

• ASTM D5800

Ambient Temperature :

• 10°C to 40°C

Relative Humidity :

• ≤85%

Power :

• 1300 W

Power Supply :

• AC 220 V ±10%, 50 Hz

Dimensions :

• 320 × 500 × 300 mm

Weight :

• 20 kg

• Touch screen LCD for easy operation
• Semi-automatic testing process
• Built-in self-lifting mechanism
• Automatic pump operation during testing
• Conforms to ASTM D5800 standard
• Noack volatility test method
• Automatic storage of test results
• LIMS (Laboratory Information Management System) support
• Precise pressure regulation
• Reliable and accurate performance
