Digital Humidity Cabinet for Oil Fuel and Petroleum Testing Instruments

The Humidity Cabinet for Rust Prevention Testing evaluates the ability of metal preservatives to protect steel panels against rusting under high-humidity conditions. Polished steel panels are immersed in the test oil and then suspended inside the humidity cabinet for a specified period. The cabinet produces a moisture-saturated atmosphere with continuous condensation at a constant temperature of 120°F (48.9°C) and accommodates 33 steel test specimens on a rotating stage. Airflow and water-level control systems maintain the required test conditions in accordance with applicable military and ASTM specifications. A digital LCD electronic controller maintains air temperature, while an adjustable digital thermostat provides over-temperature protection by cutting off power in the event of overheating. The stainless steel-lined interior and stainless steel or chrome-plated steel components provide durability. A hinged cover made of two layers of desized cotton cloth mounted on a metal frame allows convenient access. Oil and condensate dripping from the specimens are collected in a drip pan and directed to an external drain. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for corrosion prevention and metal preservative testing applications.

Testing Applications:

• Evaluation of metal preservatives for rust prevention
• High-humidity corrosion testing of steel panels

Specimen Capacity:

• 33 steel test specimens

Operating Temperature:

• 120°F (48.9°C)

Temperature Control:

• Digital LCD electronic controller
• Temperature control stability: ±2°F (±1.1°C)
• Adjustable digital over-temperature protection thermostat
• Continuous auxiliary heater circuit for initial heat-up

Water Level Control:

• 8 inches (203 mm)

Heating System:

• Heater range: 0–1500 W

Airflow System:

• Air metering: 0.878 ± 0.02832 m³/h at standard temperature and pressure (31 ± 1 ft³/h)
• 20-diffuser manifold
• Controlled airflow distribution

Rotating Stage:

• Rotation speed: 1/3 RPM

Construction and Features:

• Stainless steel-lined cabinet interior
• Stainless steel or chrome-plated steel interior components
• Hinged cover with two layers of desized cotton cloth on a metal frame
• Drip pan for collecting oil and condensate
• External drain connection

Dimensions (L × W × H):

• 32 × 28 × 41.5 inches (81 × 71 × 105 cm)

Net Weight:

• 206 lbs (93.4 kg)
