Digital Penetrometer for Petroleum Testing Equipment

The Digital Penetrometer is designed to determine the consistency and penetration characteristics of petroleum products, including lubricating greases, petroleum waxes, bitumen, pastes, creams, and other solid to semi-solid materials.

During testing, a standard cone or needle is released and allowed to penetrate the sample under controlled conditions. The penetration depth is measured in tenths or hundredths of a millimetre, typically over a standard period of 5 seconds or another specified interval. These measurements are used for product identification, quality control, and evaluation of grease consistency and shear stability.

The instrument features microprocessor-based control, programmable timing, motorized penetrator positioning, and a large LCD display. Four programmable presets simplify placement of the penetrator tip on the sample surface, while digital measurement and RS232 connectivity support convenient recording and reporting of test results.

Manufactured by Atico Export for precise and reproducible penetration testing in petroleum and industrial laboratories.

• Consistency testing of lubricating greases
• Penetration testing of petroleum waxes
• Testing of bitumen and other bituminous materials
• Evaluation of pastes, creams, and semi-solid products
• Quality control and identification of petroleum products
• Assessment of lubricating grease consistency and shear stability

Penetration Range :

• 0–62.0 mm
• 0–620 penetration units

Measurement Scale :

• 1/10 mm
• 1/100 mm

Penetration Interval :

• Adjustable from 0.1 to 9999.9 seconds
• Standard default interval: 5.0 seconds
• Automatic repeat function

Programmable Delay :

• Operator-selectable curing or temperature-stabilization period before penetration

Preset Functions :

• Four programmable penetrator positioning presets

Data Interface :

• RS232

Power Supply :

• AC operation with rechargeable battery backup

Dimensions :

• Base: 12.5 × 14 inches (31.7 × 35.6 cm)
• Overall: 12.5 × 14 × 18 inches (31.7 × 35.6 × 45.7 cm)

Net Weight :

• 9.6 kg (21 lbs)

Additional Accessories :

• Penetration cones
• Penetration needles
• Sample containers
• Constant-temperature cylinders and compatible bath accessories

• Microprocessor-based digital control
• Automatically timed, operator-programmable penetration measurements
• Standard penetration interval of 5 seconds
• Programmable penetration interval from 0.1 to 9999.9 seconds
• Motorized penetrator positioning
• Four user-programmable presets for penetrator tip placement
• Coarse and fine manual positioning controls
• Large LCD display for measurement values and operating parameters
• Digital result display and reporting
• Operator-selectable measurement resolution
• Programmable acceptance limits with audible and visual alerts for out-of-range results
• Automatic penetrator head return to the raised position
• Built-in magnifier and illuminator arms
• Automatic sample surface detection for electrically conductive samples
• Removable machined base for different sample containers
• Compatible with constant-temperature baths and cylinders
• Rechargeable battery for portable operation and backup
• Automatic battery charging during AC operation
• Complete range of compatible cones, needles, and accessories available
