Digital thermometer design Physics Lab Experiment Setup

This experiment system is designed for studying integrated temperature sensors and digital temperature measurement techniques. It enables users to investigate the temperature characteristics of integrated temperature sensors and develop practical digital thermometer designs. The system combines precise temperature control, accurate voltage measurement, and dedicated experiment modules to provide a comprehensive platform for temperature sensing and instrumentation studies.

Manufactured by Atico Export India.

Experimental Principle and Content

• Measurement of Temperature Characteristics Using an Integrated Temperature Sensor
• Design and Development of a Digital Thermometer

Digital Temperature Sensor :

• Measurement Range: -50°C to 150°C
• Accuracy: ±0.1°C

Intelligent Temperature Controller :

• Temperature Control Range: 50.0°C–120.0°C
• Adjustable Setting
• Control Accuracy: ±0.1°C

Constant Temperature Stability :

• ≤ ±0.1°C

Voltage Measurement :

• Range: 0–19.999 V
• 3½-Digit Digital Display

Experiment Module :

• Dedicated Digital Thermometer Design Module
