Digital ultrasonic velocity Physics Lab Experiment Setup by ATICO EXPORT

This experiment system is designed for the precise measurement of ultrasonic wave velocity using both standing wave and phase measurement methods. The system incorporates digital distance measurement, frequency generation, and signal processing technologies, providing an effective platform for studying ultrasonic propagation characteristics and measurement techniques in physics laboratories.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Standing Wave Ultrasonic Velocity Measurement
• Phase Method Ultrasonic Velocity Measurement

Digital Distance Measurement System :

• Measuring Range: 0–20.999 mm
• Resolution: 0.001 mm

DDS Signal Generator :

• Frequency Range: 0–100 kHz
• Continuously Adjustable
• Digital Display

Frequency Accuracy :

• ±0.1 Hz

Frequency Stability :

• ±0.1 Hz

Signal Output :

• Built-In High-Sensitivity Amplifier
• Maximum Output Power >10 W
• Amplitude Vp-p = 12 V
• Continuously Adjustable

Frequency Meter :

• Six-Digit Digital Display
• Minimum Resolution: 0.01 Hz

Waveform Selection :

• Sine Wave
• Square Wave
• Triangle Wave

Mechanical Components :

• Anti-Slip Screw Lifting Device
• Mobile Platform System, etc.
