Digital Water Spray Apparatus for Fuel Testing Instrument

The Water Spray Resistance Tester is designed to evaluate the ability of lubricating grease to adhere to a metal surface when exposed to a direct water spray under controlled conditions. The test determines the percentage of grease removed from a stainless steel test panel after a specified spraying period by measuring the weight loss.

The apparatus includes a spray chamber, water delivery system, and constant-temperature reservoir. Water is circulated through the system until thermal equilibrium is achieved, after which the grease-coated test panel is placed inside the spray chamber. Water is sprayed at a specified pressure and temperature for the required duration to assess the grease's resistance to removal.

The system incorporates a positive-displacement pump, pressure gauge, spray nozzle, bypass valve, shut-off and drain valves, and flexible high-pressure water lines. A standardized grease application fixture ensures consistent coating thickness, while separate thermometer wells allow monitoring of reservoir and spray water temperatures.

Manufactured by Atico Export for reliable water spray resistance testing of lubricating greases in lubricant testing and quality control laboratories.

• Evaluation of water spray resistance of lubricating greases
• Assessment of grease adhesion to metal surfaces
• Determination of grease loss under direct water spray
• Quality control of industrial lubricants
• Testing of grease performance under controlled water exposure

Drive Motor :

• 1/3 hp, 1725 rpm

Pump :

• Rotary gear, positive-displacement type

Pressure Gauge :

• 0–60 psi

Test Spray Pressure :

• 40 psi (276 kPa)

Test Duration :

• 5 minutes

Water Reservoir Capacity :

• 8 L

Temperature Control Stability :

• ±1°F (±0.5°C)

Test Panel :

• Stainless steel

Dimensions (L × W × H) :

• 29 × 18 × 33.5 inches (74 × 46 × 85 cm)

Net Weight :

• 110 lb (49.9 kg)

Standard Accessories :

• Stainless steel test panel
• Grease application fixture

• Complete water spray testing system
• Spray chamber with hinged acrylic cover
• Constant-temperature water reservoir
• Water delivery system with controlled spray pressure
• Positive-displacement pump
• Pressure gauge with 0–60 psi range
• Bypass, shut-off, and drain valves
• Flexible high-pressure water lines
• Separate thermometer wells for reservoir and spray water
• Standardized grease application fixture
• Uses tap water without requiring a permanent water connection
• Temperature control stability of ±1°F (±0.5°C)
