Disc Pelletizer Ø400mm

This disc pelletizer is a compact system designed for sample preparation processes, offering high precision and flexibility. Ideal for small-scale pelletizing operations in laboratory and research environments, it ensures reliable and consistent results.

• Pelletizing Disc : The device features a durable °400 x 100 x 1.5 mm stainless pelletizing disc, constructed from aluminum plating. This robust disc provides long-lasting performance, supporting extensive use.

• Adjustable Pelletizing Speed : With an adjustable pelletizing speed ranging from 0 to 50 rpm, the device offers flexible speed options to handle different materials, ensuring optimal pelletizing outcomes.

• Variable Disc Angle : The disc angle can be adjusted steplessly between 0° and 45°, allowing precise control over material flow and behavior during the pelletizing process.

• Scraper Blade : Equipped with a scraper blade made from AISI 304 stainless steel, the device effectively clears materials from the disc surface, ensuring continuous and homogeneous pellet production.

• Optional Mobile Feeder : The machine can be fitted with an optional mobile feeder, which facilitates a steady and consistent material supply during the pelletizing process.

• With its compact dimensions and flexible adjustment options, this disc pelletizer (also referred to as a pan granulator) enables excellent results in pelletizing a variety of materials. It is an ideal solution for small-scale laboratory applications and research projects.

Fields of Application :

• Iron Ore Pelletizing, Fertilizer Production, Cement Manufacturing, Coal and Carbon Pelletizing, Waste and Sludge Recycling

Application :

• Pelletizing, Agglomeration, Granulation

Power and Electricity :

• 0,55kW, 220/230V, 50/60Hz

Dimensions :

• 440mm x 750mm x 1600mm

Weight :

• 120 kg
