DOBOT Magician

Lightweight Intelligent Training Robotic Arm – An all-in-one STEAM Education Platform

DOBOT Magician is a multifunctional desktop robotic arm for practical training education. Installed with different end-tools, it can realize functions such as 3D printing, laser engraving, writing and drawing.

It supports secondary development by 13 extensible interfaces and over 20 programming languages, which allows creativity and imagination without limitation. It has received CES 2018 Innovation Award and iF DESIGN Award 2018 for its performance in hardware design and software application.

Number of Axis :

• 4

Payload :

• 500g

Max. Reach :

• 320mm

Position Repeatability (Control) :

• 0.2 mm

Communication :

• USB / WIFI / Bluetooth

Power Supply :

• 100V – 240V, 50/60Hz

Power In :

12V / 7A DC

Consumption :

• 60W Max

Working Temperature :

• -10°C – 60°C
