Dual Extraction Apparatus for Oil Fuel and Petroleum Testing Instruments

The Petroleum Extraction Apparatus determines lead, acid, or salt content in crude petroleum and petroleum products by extraction. The apparatus consists of two sets of glassware mounted on a sturdy base and upright assembly. Each set operates independently with separate line switches, rheostats, and condenser water control valves. Each glassware assembly includes a 500 mL boiling flask with heating tube, Hopkins reflux condenser with aspirator, thistle tube, 250 W heating coil, and 400 mL borosilicate glass beaker. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum extraction and analytical testing applications.

Testing Applications:

• Determination of lead content
• Determination of acid content
• Determination of salt content

Configuration:

• Two independent glassware assemblies
• Separate line switches for each assembly
• Individual rheostats
• Condenser water control valves

Standard Components:

• 500 mL boiling flask with heating tube: 2
• Hopkins reflux condenser with aspirator: 2
• Thistle tube: 2
• 250 W heating coil: 2
• 400 mL borosilicate glass beaker: 2
• Sturdy base and upright assembly

Dimensions (L × W × H):

• 17 × 11 × 36.5 inches (43 × 28 × 93 cm)

Net Weight:

• 51 lbs (23.1 kg)
