Dual Twin Foaming Characteristics Test Apparatus for Oil Fuel and Petroleum Testing Instruments

The Lubricating Oil Foaming Tester evaluates the foaming characteristics of lubricating oils under conditions involving turbulence, high-speed gearing, and high-volume pumping. Excessive foaming can cause inadequate lubrication, cavitation, overflow, and premature oxidation. The test involves blowing a controlled volume of air through the sample at specified temperatures, measuring the resulting foam at the end of each aeration period and at designated intervals afterward. The time required for the foam to collapse to zero after aeration is also measured. The system features dual liquid baths with digital temperature control for testing sequences, along with four flowmeters to maintain the required air delivery rates of 94 mL/min and 200 mL/min. An external chiller is required to perform Sequence I and Sequence III tests at 24°C. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricant foaming tendency and stability testing applications.

Testing Capacity:

• Four simultaneous tests

Temperature Control:

• Digital temperature setpoint and display
• Selectable Celsius or Fahrenheit display
• Built-in over-temperature cutoff protection

Bath Temperature Range:

• Left (cold) bath: External chiller required for Sequence I and III testing at 24°C
• Right (hot) bath: Ambient to 150°C (302°F)

Air Flow Rate:

• 94 mL/min
• 200 mL/min

Bath Capacity:

• 9 gallons (38.5 L) per bath

Standard Accessories:

• 1000 mL test cylinders: 4
• Calibrated and certified diffuser stones: 4
• Air delivery tube assemblies: 4
• Air outlet tubes: 4
• Rubber stoppers: 4
• Bath jars: 2
• Support rack: 1
• Acrylic safety shield: 18 inches

Dimensions (L × W × H):

• 32.25 × 15 × 31.25 inches (82 × 38 × 79.4 cm)

Net Weight:

• 108 lbs (49 kg)
