Dual Twin Foaming Characteristics Test Apparatus for Oil Fuel and Petroleum Testing Instruments

The Dual-Twin Lubricating Oil Foaming Tester evaluates the foaming characteristics of lubricating oils under conditions involving turbulence, high-speed gearing, and high-volume pumping. Excessive foaming can cause inadequate lubrication, cavitation, overflow, and premature oxidation. The test involves passing a controlled volume of air through the sample at specified temperatures and measuring the resulting foam at the end of each aeration period and at designated intervals afterward. The system performs two tests at 24°C (75°F) and two tests at 93.5°C (200°F) simultaneously. It consists of two constant-temperature baths equipped with microprocessor temperature controls, copper immersion heaters, and circulation stirrers to maintain temperature uniformity. PID control enables rapid temperature stabilization while minimizing overshoot, and an over-temperature protection circuit interrupts power if the bath exceeds the programmed cutoff. Dual LED displays show actual and setpoint temperatures in Celsius or Fahrenheit. The cold bath includes coils for cooling exhaust air from the high-temperature tests and for circulating cooling water or refrigerant when required. The system also supports automatic time-sequence testing, with custom configurations available for specialized applications. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricant foaming characteristics testing.

Testing Applications:

• Standard lubricating oil foaming tests

Testing Temperatures:

• Cold bath: 24°C (75°F)
• Hot bath: 93.5°C (200°F)

Testing Capacity:

• Four simultaneous tests
• Two tests at 24°C
• Two tests at 93.5°C

Temperature Control:

• Microprocessor PID temperature control
• Digital setpoint and actual temperature displays
• Selectable Celsius or Fahrenheit display
• Temperature uniformity: ±1°F (±0.5°C)
• Built-in over-temperature cutoff protection

Air Flow Rate:

• 94 mL/min per sample

Bath Specifications:

• Two constant-temperature baths
• Bath capacity: 9 gallons (38.5 L) each
• Bath dimensions: 12 × 18 inches (30.5 × 45.7 cm)
• Copper immersion heaters
• 1/20 HP circulation stirrers
• Cooling coils in the cold bath for exhaust air and cooling water or refrigerant circulation
• Quick-locking cams for securing test cylinders
• Separate stainless steel support rack
• Finished steel base with chemical-resistant polyurethane enamel coating

Standard Accessories:

• 1000 mL test cylinders: 4
• Calibrated and certified diffuser stones: 4
• Air delivery tube assemblies: 4
• Air outlet tubes: 4
• Rubber stoppers: 4
• Bath jars: 2
• Support rack: 1
• Acrylic safety shield: 18 inches

Optional Features:

• Automatic time-sequence operation
• RS232 communication software
• Ramp-to-set temperature control
• Custom configurations for specialized applications

Dimensions (L × W × H):

• 32.25 × 15 × 31.25 inches (82 × 38 × 79.4 cm)

Net Weight:

• 108 lbs (49 kg)
