Elastic line of a beam Deluxe

Beams are important design elements in mechanical engineering and building construction that can deform under load. Beams are subjected to load transversely in the axial direction, which leads to deflection. In linear–elastic material behaviour, the bending line, also known as elastic line, is used to determine the deflection of beams. Learn about Elastic line of a beam exporters for optimal educational outcomes.. Deflection can be determined at any point on the beam using the influence coefficients and Maxwell–Betti’s commutative theory.

• determine the elastic line
• beams of different materials: steel, brass and aluminium
• 2 articulated supports
• 1 fixed support with clamp
• dial gauges for recording the deformation of the beam
• storage system for parts
• experiment setup in the SE 112 mounting frame
