ELASTIC SHAFT MODULE

An optional module for a machinery diagnostics base unit designed to show and analyse faults that can occur with a shaft in a rotating system. Demonstrates how to diagnose problems and identify differences between various types of shaft fault using vibration analysis.

• Aluminium shaft: Length 381 mm (15"); nominal bearing span 250 mm
• Shaft diameter: 12.7 mm
• Two weight discs, adjustable along shaft length
• 8 × grub screws installed in rotors
