Electric Field Mapping Apparatus

Experiments :

• Study of electrostatic fields using the simulation method.

Experiments :

• Understanding the concepts of electric field intensity and electric potential.

Experiments :

• Mapping and analysis of equipotential lines and electric field lines for coaxial cable and parallel-wire electrode configurations.

DC Power Supply :

• Output Range: 0–15 V DC.
• Continuously adjustable.

Digital Voltmeter :

• Measuring Range: –19.99 V to 19.99 V.
• Resolution: 0.01 V.

Parallel-Wire Electrodes :

• Electrode Diameter: 20 mm.
• Distance Between Electrodes: 100 mm.

Coaxial Electrodes :

• Central Electrode Diameter: 20 mm.
• Ring Electrode Width: 10 mm.
• Distance Between Electrodes: 80 mm.

Standard Accessories :

• Main Electrical Unit – 1 No.
• Conductive Glass and Carbon Paper Support – 1 No.
• Probe and Needle Support – 1 No.
• Conductive Glass Plates – 2 Nos.
• Connection Wires – 4 Nos.
• Carbon Paper Pack – 1 No.

Optional Conductive Glass Plates :

• Focusing Electrode.
• Non-Uniform Field Electrode.

Manufactured By :

• Atico Export India for precision Physics Lab Experiments.
