Electrical Handling Workstation

The is an electrical handling system commanded by a PLC.

ATENG 12575 — Electrical Handling Workstation. The system is equipped with different sensors in order to identify the piece color and position.

• The “ATENG 12575” workstation has been designed as a modular system to facilitate the understanding of the equipment operation:
• The PLC: is composed of an AE-PLCB that contains a HMI device, analog and digital input/output modules, etc. and the required
  extra modules to put into operation the workstation successfully.
• The control panel: emergency stop push button switch, start/stop button, reset button, light indicator to show the state of the workstation,
  etc.
• The pneumatic circuit: contains the required solenoid valves, filters and regulators to assure the correct working and safety of the unit.
• The workstation: is composed of real components used by the industrial automatic conveyor systems such as: capacitive sensors, limit
  switch sensors, position sensor, etc.
  The “ATENG 12575” workstation can work alone and/or in conjunction with other workstations to make up a complete Flexible Manufacturing
  system*.
• The Flexible manufacturing systems product list is available at the “60.-MECHATRONICS, AUTOMATION AND COMPUMECHATRONICS”
  area.
