Electrical Motor System

• Familiarization of a wide range of motors used in industry
• Learn motor specifications relative to size and power output
• Study wiring connections between motors and control systems

• DC Shunt Wound Motor
• DC Series Wound Motor
• DC Compound Wound Motor
• AC Single Phase Induction Motor
• AC Single Phase Split-Pole Motor
• AC Single Phase Repulsion Motor
• AC Single Phase Universal Motor
• AC Three Phase Induction Squirrel Cage Motor (4 Pole)
• AC Three Phase Asynchronous Pole Changing Motor
• AC Three Phase Asynchronous Slip-Ring Motor
• AC Three Phase Rotor Wound Motor
• AC Single Phase Split-Phase Motor
• AC Single Phase Capacitor Start/Run Motor
• AC Single Phase Reluctance Motor
• AC Three Phase Synchronous Reluctance Motor
• AC Three Phase Induction Squirrel Cage Motor (2 Pole)
• AC Three Phase Synchronous Salient Pole Motor

Safe operation with terminal sockets for student protection
