Electrostatics in any humidity:
- This experiment set covers electrostatics, magnetostatics and electromagnetic induction
- Complements basic circuit studies from ELECTRICITY 1
- Carefully selected materials allow electrostatics experiments even in high humidity conditions
Amazingly distinct magnetic field lines:
- Specially grained iron filings produce very clear magnetic field patterns
- A perspex platform enhances visibility and structure of field lines
- Enables observation of the three-dimensional nature of magnetic fields
Right to the nub of electromagnetic induction:
-
Using the 100 mV range of the AMM 300 analog multimeter allows precise measurements
-
Zero-point calibration enables clear observation of induction effects
-
Experiments on AC generators become highly demonstrative
-
Transformer laws can also be explored easily and effectively
Included items:
- 1 × Storage case
- 1 × Inlay with cut-outs for apparatus, E2
- 1 × Glowlamp on base
- 1 × Battery holder with 3 AA batteries
- 1 × Multi-purpose base
- 1 × Base with sockets
- 1 × Shaker with iron filings
- 2 × Iron keepers
- 2 × AlNiCo cylindrical magnets
- 7 × Iron washers in box
- 1 × Field line platform
- 1 × Iron bar E1
- 1 × Pivot bearing
- 1 × Needle stand
- 1 × Electroscope
- 1 × U-shaped core with yoke
- 1 × Coil with 200/400 windings
- 1 × Coil with 300/600 windings
- 1 × Perspex rod
- 2 × PVC rods
- 1 × Woolen cloth
- 1 × Silk cloth
- 1 × Closed aluminium ring
- 1 × Open aluminium ring
- 4 × Experiment leads, 25 cm, red
- 2 × Experiment leads, 25 cm, blue
Experiments:
- Magnetic poles
- Action and reaction as applied to magnetism
- Magnetic effects
- Magnetic field lines
- A magnet that can be turned on and off**
- Soft iron instruments**
- Electrostatic force
- Electroscopes
- Sign of electric charge
- Electromagnetic induction*
- Lenz’s law
- Self-induction
- Transformer laws**
- AC generators*
- DC motors
