Electrics 4 Lorentz Force Physics Science Kits for Lab Use in Schools & Colleges ATICO Export

The Lorentz force:

• The ELECTRICITY 4 experiment set demonstrates the Lorentz force on a current-carrying conductor

• Enables clear investigation of vector properties of the force

• Shows dependence on:

• Strength of electric current

• Strength of magnetic field

• Angle between current direction and magnetic field

• Also allows precise determination of magnetic field strength

Coil, conductor boards and base plate:

• Includes a 15 cm long coil with 950 windings to generate a magnetic field
• Five conductor boards with different lengths and orientations are provided
• A base plate and conductor tracks form a sensitive current balance
• The system can be easily adjusted to equilibrium
• A set of compensating weights is included for accuracy

Included items:

• 1 × Storage box
• 1 × Inlay with cut-outs for E4
• 1 × Base plate E4
• 1 × PCB 25/90°
• 1 × PCB 35/90°
• 1 × PCB 50/90°
• 1 × PCB 50/65°
• 1 × PCB 50/75°
• 1 × Straight blunt tweezers
• 1 × Acrylic glass plate with pin
• 1 × Set of compensating masses in can
• 1 × Field coil
• 4 × PCB holder
• 10 × Rubber cap for needle stand
• 2 × Experiment cable 34 cm blue
• 4 × Experiment cable 25 cm blue

Experiments:

• Vector properties of the Lorentz force
• Lorentz force and magnetic field strength
• Lorentz force and current
• Lorentz force and length of conductor
• Lorentz force and the angle between the field and the current flow
• Determining magnetic field strength
