Electrics Addestation Physics Science Kits for Lab Use in Schools & Colleges ATICO Export

Data logging and sensors:

• Demonstrative experiments on electromagnetic induction, transformers, rectification and coil switching typically require a dual-channel oscilloscope

• This allows clear visualization of phase differences between primary and induced voltages

• Due to cost, providing such equipment for every student was previously not feasible

• The ELECTRICITY 5 ADDESTATION set uses MGA software to simulate an oscilloscope

• It can display up to four parameters simultaneously

• Especially useful for:

• Half-wave and full-wave rectification

• Transformer behavior and phase relationships

• Measurements can be displayed:

• Graphically with colour-coded curves

• Digitally

• As vector diagrams

• Data can be automatically:

• Transferred into tables

• Plotted into graphs

• Used to generate equations of straight lines

Visualisation of readings:

• Digital and vector diagram displays improve understanding of results
• Particularly effective for deriving Ohm’s law
• Graphs and equations can be displayed instantly by selecting functions
• Enables clear analysis of relationships between variables

Included items:

• 1 × Storage case
• 1 × Inlay with cut-outs for E5
• 1 × Base plate E5
• 2 × Coupling E7
• 1 × Switching element
• 2 × Sensor connection cable
• 1 × Bulb element E5
• 1 × Current sensor
• 1 × Switch element
• 2 × Voltage sensor
• 1 × Potentiometer element
• 2 × End plate E5
• 1 × Acrylic glass tube with scale A1
• 2 × Round rod magnet AlNiCo
• 1 × Transistor element E5
• 1 × Screw spring 10 N/m
• 1 × Test tube with hook
• 1 × Resistance element R1
• 1 × Resistance element R2
• 1 × Resistance element R3
• 1 × Resistance element R4
• 1 × Si-diode element
• 1 × Capacitor element 4.7 μF
• 1 × Capacitor element 10 μF
• 1 × Capacitor element 47 μF
• 1 × Coil with 300/600 turns
• 2 × Experiment cable 8.5 cm
• 2 × Experiment cable 17 cm
• 2 × Experiment cable 34 cm blue
• 1 × Adjusting plate
• 1 × Bridge rectifier circuit element
• 3 × Experiment cable 25 cm blue
• 1 × Resistance element 1 kΩ
• 1 × Resistance element 10 kΩ
• 1 × Resistance element 22 kΩ
• 4 × Shorting link

Experiments:

• V-I characteristic for an incandescent bulb
• Ohm’s law
• Determining resistance values
• Internal resistance of a battery
• Electromagnetic induction
• Induction pendulums
• AC generators
• Transformers
• Half-wave rectification
• Full-wave rectification
• Charging and discharging of a capacitor
• Smoothing
• Capacitive resistance
• Inductive resistance
• Resonant circuit 1
• Resonant circuit 2
