Electrostatics in any humidity:

• The ELECTRICITY 2 plus experiment set covers:

• Electrostatics

• Magnetostatics

• Electromagnetic induction

• Magnetic field of a coil

• Lorentz force

• Compared to the standard ELECTRICITY 2 set, this version also includes experiments on:

• Magnetic field of a coil

• Lorentz force

• Carefully selected materials and design ensure that electrostatics experiments work even at very high humidity

Amazingly distinct magnetic field lines:

• Specially grained iron filings produce clear and well-defined magnetic field patterns
• A perspex platform enhances visibility
• Enables observation of three-dimensional magnetic field structures

Right to the nub of electromagnetic induction:

• The 100 mV range of the AMM 300 analog multimeter allows precise measurements

• Zero-point calibration improves accuracy and clarity

• AC generator and induction experiments become highly demonstrative

• Transformer laws can also be explored effectively

Accessories required:

• Multimeters and low-voltage power supplies are not included
• These can be used across multiple experiment sets
• An eddy current set is required for eddy current experiments

Supplementary materials:

• A student workbook is available
• A teacher’s guide with background information and solutions is also provided

Included items:

• 1 × Storage case
• 1 × Inlay with cut-outs for apparatus, E2 plus
• 1 × Glowlamp on base
• 1 × Battery holder with 3 AA batteries
• 1 × Multi-purpose base
• 1 × Base with sockets
• 1 × Shaker with iron filings
• 2 × Iron keepers
• 2 × AlNiCo cylindrical magnets
• 7 × Iron washers in box
• 1 × Field line platform
• 1 × Iron bar E1
• 1 × Pivot bearing
• 1 × Needle stand
• 1 × Electroscope
• 1 × U-shaped core with yoke
• 1 × Coil with 200/400 windings
• 1 × Coil with 300/600 windings
• 1 × Perspex rod
• 2 × PVC rods
• 1 × Woolen cloth
• 1 × Silk cloth
• 1 × Closed aluminium ring
• 1 × Open aluminium ring
• 2 × Rod holder E2+
• 4 × Experiment leads, 25 cm, red
• 2 × Experiment leads, 25 cm, blue
• 1 × Material samples in box E2+
• 2 × Field line plates wide
• 1 × Field line plate narrow

Experiments:

• Ferromagnetic materials
• Magnetic poles
• Elementary magnets
• Magnetic induction
• Force and counterforce in magnetism
• Magnetic field lines
• Magnetic field of a coil
• A magnet for switching on and off**
• The soft iron instrument**
• Electrostatic force
• Electroscopes
• The sign of electric charge
• Electromagnetic induction 1*
• Electromagnetic induction 2*
• The Lorentz force
• Lenz’s law
• Self-induction
• The transformer laws**
• The AC generator*
• The DC motor
• Eddy currents***
