Electrics Equipotential Lines Physics Science Kits for Lab Use in Schools & Colleges ATICO Export

Large effective surface for experiments:

• The key component is a basin measuring 243 × 208 mm with a transparent base

• The base is printed with a three-colour coordinate system

• Enables easy transfer of equipotential points onto printed paper

• Electrode holders are made of high-quality plastic

• Their compact design ensures minimal obstruction of the potential field view

• Equipped with sockets for leads and knurled screws for secure electrode attachment

Normal tap water:

• Experiments can be performed using normal tap water
• Adjustable screw feet allow precise leveling of the basin for accurate results

Versatile experiments:

• Six interchangeable electrodes allow a wide range of electric field experiments
• Equipotential lines can be studied effectively
• Experiments are conducted using AC voltage
• A digital multimeter with high input resistance is used for measurements

Included items:

• 1 × Storage box
• 1 × Inlay with cut-outs for E6
• 1 × Tub
• 2 × Electrode holder E6
• 1 × Plastic cup, 100 ml
• 2 × Resistor element 1 kΩ/1%
• 2 × Plate electrode E6
• 1 × Angled electrode
• 1 × Cylinder electrode E6
• 2 × Sharp electrode
• 1 × Experiment cable 8.5 cm
• 2 × Experiment cable 17 cm
• 2 × Experiment cable 34 cm blue
• 2 × Experiment cable 25 cm blue

Experiments:

• Plate capacitors
• Electric dipoles
• Image charges
• Conductors in an electric field
• Lightning conductors
• Two circular but eccentric electrodes
• Faraday’s cage
• Two concentric electrodes
• One flat and one cylindrical electrode
• Potential of a point charge
• Two point charges of equal potential
• Potential between two unlike charges
