Electro Optic Acousto Optic Magneto Optic Effect Physics Lab Experiments Setup

This comprehensive optics experiment system provides a versatile platform for studying electro-optic, acousto-optic, and magneto-optic phenomena through hands-on experimentation. Crystal materials subjected to electric fields, magnetic fields, or mechanical stress exhibit changes in their optical properties, enabling the modulation of light intensity, phase, and polarization.

This physics laboratory experiment system, manufactured by Atico Exports, provides a comprehensive platform for studying geometric optics, wave optics, interference, diffraction, holography, polarization, and information optics through hands-on experimentation.

The system integrates multiple optical modulation techniques into a single experimental platform, allowing users to investigate a wide range of photonic effects while developing practical laboratory skills and a deeper understanding of modern optical technologies.

Experimental Principles

• Electro-optic effect studies
• Acousto-optic modulation
• Magneto-optic modulation
• Birefringence phenomenon investigation
• Light intensity modulation
• Optical phase modulation
• Polarization control and analysis
• Optical material characterization

• Physics laboratory experiments
• Electro-optic and acousto-optic studies
• Magneto-optic measurements
• Optical modulation demonstrations
• Photonics education and training
• Optical communication technology studies
• Advanced optics laboratory research

Light Source:

• Visible gas laser or semiconductor laser

Optical Components:

• Polarizing prisms
• Wave plates
• Optical glass components
• Additional polarization optics

Adjustment & Mounting System:

• Optical guide rail
• Projection screen
• Rotational mounts
• Sliding stages
• Precision slit assembly

Electro-Optic Crystal:

• X-side electrode configuration
• Optical transmission range: 420–520 nm

Modulation Coils:

• Large modulation coil
• Small modulation coil

Main Control Unit:

• Signal generation and output
• Optical signal reception
• Measurement and display functions

Acousto-Optic Driver:

• Integrated drive power supply

Horizontal Scanning Mechanism:

• Resolution: 0.01 mm
• Travel range: >100 mm
