Electromagnetic sensor characteristic Physics Lab Experiment Setup

This experiment system is designed for studying the characteristics and applications of electromagnetic sensors in displacement, force, and material property measurements. It enables the calibration of electromagnetic sensors and their use in determining the linear expansion coefficient and Young’s modulus of metallic materials. The system combines precise temperature control with high-resolution displacement and force measurement, providing an effective platform for advanced experimental studies.

Manufactured by Atico Export India.

Experimental Principle and Content

• Study and Calibration of Electromagnetic Sensor Characteristics
• Measurement of the Linear Expansion Coefficient of Solids Using Electromagnetic Sensors
• Determination of Young’s Modulus of Metals Using Electromagnetic Sensors

Intelligent Temperature Control System :

• Temperature Range: Room Temperature to 120.0°C
• Continuously Adjustable
• Accuracy: ±0.1°C

Digital Temperature Sensor :

• Measurement Range: -50°C to 125°C
• 3½-Digit Digital Display
• Accuracy: ±0.1°C

Electromagnetic Sensor Displacement Measuring Instrument :

• Measuring Range: 0–1999 mV
• 0–2000 mm

Digital Tension Measuring Instrument :

• Measuring Range: 0–1999 kg
• Continuously Adjustable
• Accuracy: ±0.01 kg

Calibration Device :

• Electromagnetic Sensor Displacement Calibration Device
