Electron Diffraction Experimental Apparatus for Advanced Physics Lab

The Electron Diffraction Experimental Apparatus for Advanced Physics Lab is designed to demonstrate the wave nature of electrons and verify the fundamental principles of quantum mechanics. Based on the concept of wave-particle duality, the apparatus enables students to observe electron diffraction and experimentally confirm that electrons exhibit both particle and wave characteristics. The system features a specially designed electron diffraction tube with a transparent viewing window for clear observation. An electron gun generates and accelerates electrons toward a thin polycrystalline gold foil target. As the accelerated electrons interact with the crystalline structure, distinct diffraction rings are produced on a fluorescent screen, allowing both qualitative observation and quantitative analysis. With its precise construction and high-quality diffraction tube, the apparatus provides bright, sharp, and stable diffraction patterns, making it an ideal teaching and research instrument for physics laboratories. Manufactured by Atico Export India.

Determine the Wavelength of Moving Electrons:

• Measure the wavelength of accelerated electrons
• Verify the de Broglie wavelength relationship

Verify the de Broglie Equation:

• Demonstrate the wave-particle duality of matter
• Study electron diffraction phenomena

Measure the Lattice Constant of Crystalline Gold:

• Use diffraction data to calculate lattice spacing
• Analyze the structure of the polycrystalline gold target

Determine Miller Indices of Diffraction Rings:

• Analyze diffraction ring patterns
• Identify corresponding crystal planes

Calculate Planck’s Constant:

• Utilize experimental measurements to determine Planck’s constant
• Reinforce fundamental concepts of quantum physics

DC High Voltage:

• 0 – 20 kV Adjustable
• Current: 0.8 mA

Filament Voltage:

• 6.5 V

Diffraction Tube Screen Diameter:

• 130 mm

Diffraction Target:

• Polycrystalline Gold Foil
• Diameter: 15 mm

Dimensions:

• 360 mm × 200 mm × 520 mm

Parts List:

Main Unit with Electron Diffraction Tube:

• Quantity: 1

Power Cord:

• Quantity: 1

Instruction Manual:

• Quantity: 1

• Long-Life Electron Diffraction Tube
• Clear and Sharp Diffraction Rings
• Excellent Isolation Between High-Voltage and Low-Voltage Circuits
• High Measurement Accuracy
• Bright and Well-Defined Diffraction Patterns
• Suitable for Advanced Physics Laboratory Experiments
