Electron Diffraction Instrument Advanced Physics Experiment

This electron diffraction experiment system is designed to demonstrate the wave nature of electrons and verify the principles of quantum mechanics through electron diffraction. It enables students to observe the diffraction patterns of polycrystalline materials, verify the wave-particle duality of microscopic particles, and determine the lattice constants of crystalline materials by analyzing diffraction ring patterns. The system provides a comprehensive platform for modern physics and quantum mechanics laboratory experiments. Physics Lab Experiments from Atico Exports.

Input Voltage :

• AC 220 V
• 50/60 Hz

Anode Voltage :

• DC 0–19 kV
• Continuously adjustable
• Three-and-a-half digit display

Filament Voltage :

• AC 6.5 V

Beam Current :

• 0.8 mA

Fluorescent Screen Size :

• Diameter: 130 mm

Diffraction Sample :

• Polycrystalline Gold (Au)
• Diameter: 15 mm

Diffraction Ring Width :

• Less than 0.5 mm

Electron Beam Displacement :

• Electrostatic displacement method

Overall Dimensions :

• 360 × 200 × 520 mm

Instrument Housing :

• Aluminum-plastic shockproof carrying case

Display :

• Electron diffraction ring pattern observation
