Electron Spin Resonance ESR Apparatus

This Electron Paramagnetic Resonance (EPR) experiment system is designed to demonstrate the fundamental principles of electron paramagnetic resonance and magnetic resonance spectroscopy. It enables students to study EPR phenomena, measure the Landé g-factor, determine the resonance linewidth of DPPH samples, and gain practical experience in magnetic resonance measurement techniques. The system includes a frequency meter for accurate frequency measurement. Note: Oscilloscope is not included. Manufactured by Atico Export India.

Experiments :

• Study the Fundamental Principles, Experimental Phenomena, and Measurement Methods of Electron Paramagnetic Resonance (EPR).
• Measure the Landé g-Factor and Resonance Linewidth of a DPPH Sample.

RF Frequency :

• 28–33 MHz
• Continuously adjustable

Magnetic Field Type :

• Spiral coil magnetic field

Magnetic Field Strength :

• 6.8–13.5 Gs

Magnetic Field Voltage :

• DC 8–12 V

Sweep Voltage :

• AC 0–6 V
• Continuously adjustable

Sweep Frequency :

• 50 Hz

Sample Space :

• Ø5 × 8 mm

Experimental Sample :

• DPPH

Measurement Accuracy :

• Better than 2%

Frequency Meter :

• Included

External Equipment Required :

• Oscilloscope (not included)
