Enhanced Portable Fuel Analyzer for Petroleum Testing Equipment

The Portable Fuel Quality Analyzer is designed to evaluate the quality of gasoline and diesel fuels by measuring octane-related parameters and, with optional calibrations, cetane index, cetane number, ethanol content, and biodiesel percentage.

The instrument uses near-infrared optical technology to analyze fuel samples quickly and conveniently at fuel stations, terminals, refineries, and production facilities. It is pre-calibrated for Research Octane Number (RON), Motor Octane Number (MON), and the Anti-Knock Index (AKI), also expressed as (R+M)/2.

The analyzer features automatic fuel detection, temperature compensation, self-standardization, and a full-colour display. Results can be stored internally, printed with the date and time, or transferred to a computer through the USB interface. No sample preparation is required, and the measurement process does not consume or destroy the sample.

Manufactured by Atico Export for rapid fuel quality assessment and on-site petroleum testing applications.

• Determination of Research Octane Number (RON) in gasoline
• Determination of Motor Octane Number (MON)
• Measurement of Anti-Knock Index (AKI)
• Testing of unleaded and leaded gasoline
• Analysis of ethanol-blended gasoline
• Optional diesel cetane index and cetane number analysis
• Optional measurement of ethanol content and biodiesel percentage
• On-site fuel quality testing at fuel stations, terminals, and production facilities

Measurement Parameters :

• Research Octane Number (RON)
• Motor Octane Number (MON)
• Anti-Knock Index (AKI), (R+M)/2
• Optional diesel cetane index and cetane number
• Optional biodiesel percentage and additional fuel calibrations

Measurement Method :

• Diffuse transmittance using near-infrared optics

Spectral Range :

• 16 optical filters covering wavelengths from 810 to 1045 nm

Scan Speed :

• Up to 10 scans per second

Optical Range :

• 0 to 6 AU

Optical Resolution :

• 0.00001 AU

Optical Stability :

• 0.05 milli-absorbance units (mAU)

Measurement Time :

• Typically under 25 seconds
• Approximately 45 seconds for specified octane analysis

Sample Size :

• 200 mL

Sample Path Length :

• 75 mm

Sample Holder :

• Reusable glass holder with chemical-seal cover

Sample Preparation :

• Not required

Sample Destruction :

• Non-destructive analysis

Data Storage :

• Up to 100 samples

Calibration Storage :

• Up to 10 calibration sets

Data Transfer :

• USB interface

Dimensions (W × D × H) :

• 4.5 × 13.5 × 2.2 inches (12 × 33 × 5 cm)

Net Weight :

• Less than 2 kg (approximately 3 lbs)

Standard Accessories :

• Built-in printer
• USB interface
• Fuel calibration and data analysis software
• Reusable glass sample holder with chemical-seal cover

Optional Accessories :

• Additional diesel fuel calibration
• Additional biodiesel calibration
• Cigarette lighter adapter
• Extended one-year warranty
• Replacement printer mechanism
• Printer paper, pack of 10 rolls
• Sample holders, box of 12
• Light shield
• Aluminium sample carrying case with 12 sample holders
• Sample holder lids, quantity 12
• Sample holder labels, quantity 12
• GPS locator

• Portable design for on-site fuel analysis
• Near-infrared optical measurement technology
• Quick and convenient fuel quality readings
• Typical analysis time under 25 seconds, depending on the test; approximately 45 seconds for specified octane analysis
• Optional calibrations for diesel, cetane, and biodiesel analysis
• Automatic gasoline, ethanol-blended gasoline, and diesel detection
• Automatic temperature compensation
• Self-standardization for measurement consistency
• Full-colour display for different lighting conditions
• Built-in printer with date and time of analysis
• Internal storage for up to 100 samples
• Stores up to 10 calibration sets
• USB data transfer to a laptop, tablet, or computer
• Calibration and data analysis software included
• Reusable glass sample holder with chemical-seal cover
• No sample preparation required
• Non-destructive sample analysis
