Equilibrium of moments on a differential pulley block

This experimental unit illustrates the equilibrium conditions on a differential pulley block. The relation between pulley diameter, lifting force and torque is demonstrated.

• investigation of the equilibrium of moments on a differential pulley block
• anodised aluminium pulleys
• 1 loose roller
• ball bearing-mounted steel shaft
• bracket for wall mounting
