EQUILIBRIUM OF PARALLEL FORCES

Two plastic models engraved to simulate a Warren truss and an 'N' truss are used for the application of vertical loads and reactions. A circular disc with twelve attachment points is used for couple experiments. Each model has a counterbalancing weight to render it effectively 'weightless', simplifying results. Learn about EQUILIBRIUM OF PARALLEL FORCES specifications for optimal educational outcomes.. The lines of action of the cords can be transferred onto a sheet of paper clipped to a force board. Forces are produced with cords tensioned by weights on hangers, with double pulleys used to redirect upward forces downward. Learn about EQUILIBRIUM OF PARALLEL FORCES price for optimal educational outcomes..

• Warren Truss: 300 (L) × 3 (W) × 100 (H) mm, engraved with truss outline
• 'N' Truss: 412 (L) × 3 (W) × 112 (H) mm, engraved with truss outline
• Reaction Disc: Ø210 × 3 mm, with 12 equi-spaced holes
• Accessories: 1 × hook set, counterbalance weight set
• Weights set: 4 × 0.1 N, 8 × 0.2 N
