EQUILIBRIUM OF RIGID BODY

Apparatus for investigating the equilibrium of a rigid body (ladder) under various loading conditions and angles.

• Ladder length: 560 mm (approx.)
• Increments: every 70 mm
• Movable weight: secured with knurled thumbscrew
• Ladder angle range: 10° to 45° during experiments
• Sliding mass: 0.5 kg (approx.)
