Equipment Set for Laser Communication Physics School Science STEM Kit

Function and Applications:

• Experiment system for transmitting audio and video signals using a laser beam

• Consists of:

  • Power supply for laser diode with adjustable output power
  • Audio and video inputs for modulation of the laser beam
  • Receiver unit with integrated amplifier

• Receiver unit includes CINCH connectors for:

  • Loudspeakers
  • TV set

• Also includes:

  • Microphone
  • Loudspeaker

• Audio signals are transmitted using frequency modulation (FM)

• Video signals are transmitted using amplitude modulation (AM)

• For video transmission, any PAL or NTSC video camera can be connected
  (camera not included)

• Includes:

  • Universal plug-in power supplies
  • Storage case

Specifications:

• Laser diode:

  • Laser protection class II

• Wavelength:

  • 635 nm

• Laser power:

  • 0.2 to 1 mW continuously adjustable

• Plug-in power supply:

  • Primary: 100 to 240 V AC, 50/60 Hz
  • Secondary: 12 V DC
