Evaporation process

Visualises evaporation in a tube evaporator, tracing the medium from fluid to superheated vapour. This unit teaches critical boiling crisis knowledge to ensure the safe design of industrial steam generators.

• visualisation of evaporation in a double-wall glass tube
• closed-loop heating circuit with heater, pump, and expansion vessel
• water jet pump for evaporation circuit evacuation
• refrigerant R1233zd used, GWP: 4
• safety valve overpressure protection
