Existent Gum Evaporation Bath for Petroleum Testing Equipment

The Gum Content Tester is designed to determine the existent gum content in aviation gasoline, motor gasoline, and aircraft turbine fuels. Gum formed during fuel storage can deposit on induction system surfaces, intake valves, stems, and guides, potentially affecting engine performance.

During testing, a 50 mL fuel sample is evaporated under controlled temperature and flow conditions for a specified period. Air-jet evaporation is used for motor and aviation gasolines, while steam-jet evaporation is used for aircraft turbine fuels.

The apparatus features an electrically heated aluminium block bath, digital flowmeter, pressure regulators, and microprocessor-based temperature control. Stainless steel jets deliver air or steam through removable brass conical adapters to ensure controlled evaporation conditions.

Manufactured by Atico Export for reliable gum content determination and quality control in petroleum fuel testing laboratories.

• Determination of existent gum in motor gasoline
• Testing of aviation gasoline
• Gum content determination in aircraft turbine fuels
• Evaluation of fuel storage stability and deposit-forming tendencies
• Quality control of petroleum fuels

Testing Capacity :

• Six sample beakers for the six-unit model
• Three sample beakers for the three-unit models

Maximum Bath Temperature :

• 246°C (475°F)

Temperature Control Stability :

• ±0.5°C (±1°F)

Bath Configuration :

• Machined aluminium block with multiple cartridge heaters

Heater Power Range :

• Six-unit model: 0–3000 W
• Three-unit models: 0–1500 W

Built-in Steam Superheater :

• Available on the six-unit model
• Stainless steel superheating chamber and condensate trap
• Solid-state temperature regulator
• Temperature control range: 0–550°F
• Heater power range: 0–3000 W

Steam Generator :

• Output: 54.1 lbs of steam per hour at 212°F
• Boiler horsepower rating: 1.83 BHP
• Power rating: 18 kW

Dimensions (W × D × H) :

• Six-unit model: 21 × 20.5 × 28 inches (53.34 × 52.07 × 71.12 cm)
• Three-unit models: 32.5 × 11 × 19 inches (83 × 28 × 48 cm)

Net Weight :

• Six-unit model: 104.3 kg (230 lbs)
• Three-unit models: 38.6 kg (85 lbs)

Additional Features of Steam Generation System :

• Electrically heated boiler for steam-jet evaporation testing
• Automatic water-level control
• Low-water cut-off
• Steam safety valve
• High-limit pressure cut-out with manual reset
• Steam pressure gauge
• Industrial-grade heating element
• Requires a water supply and electrical connection

• Available in three-unit and six-unit models
• Electrically heated aluminium block bath
• Air-jet evaporation for motor and aviation gasolines
• Steam-jet evaporation for aircraft turbine fuels
• Safety top assembly for convenient positioning of conical adapters
• Digital flowmeter for accurate airflow measurement
• Built-in pressure regulators and airflow control
• Optional built-in steam superheater
• Microprocessor-based PID temperature control
• Rapid temperature stabilization with minimal overshoot
• Dual LED displays for actual and setpoint temperatures in °C or °F
• Overtemperature protection with automatic power interruption
• Stainless steel jets and removable brass conical adapters
• Insulated construction for safe and efficient high-temperature operation
