Experimental System for Crystal Magneto Optic Effect

This magneto-optic experiment system is designed to study the Faraday effect and the interaction between light and magnetic fields. It enables students to measure the Faraday rotation angle, determine the Verdet constant of optical materials, characterize magneto-optic glass, and demonstrate optical communication using magneto-optic modulation techniques. Physics Lab Experiments from Atico Exports.

Experiments :

• Measure the Faraday Rotation Angle.
• Calculate the Verdet Constant of a Material.
• Characterize Magneto-Optic Glass.
• Demonstrate Optical Communication Using Magneto-Optic Modulation Technique.

Light Source :

• Semiconductor laser
• 650 nm
• 10 mW

DC Excitation Current :

• 0 – 1.5 A
• Continuously adjustable

DC Magnetic Induction :

• 0 – 100 mT

Broadcaster :

• Loudspeaker box
