Experimental System for Polarized Light Experiment

This polarization optics experiment setup is designed to demonstrate the fundamental principles of polarized light through a variety of practical experiments. The system enables students to study polarization, wave plates, Brewster's angle, and the behavior of linearly, circularly, and elliptically polarized light using precision optical components. Manufactured by Atico Export India.

Experiments :

• Measure Brewster’s Angle of a Black Glass Plate.
• Verify Malus’s Law.
• Study the Function of a λ/2 Wave Plate.
• Study the Function of a λ/4 Wave Plate for Circularly and Elliptically Polarized Light.

Optical Rail :

• Duralumin, 1 m

General Carrier :

• Standard
• Quantity: 3

X-Adjustable Carrier :

• Adjustable
• Quantity: 1

X-Z Adjustable Carrier :

• Adjustable
• Quantity: 1

Alignment Screen :

• Standard
• Quantity: 1

Lens Holder :

• Standard
• Quantity: 2

Plate Holder :

• Standard
• Quantity: 1

Adaptor Piece :

• Standard
• Quantity: 1

Optical Goniometer :

• Standard
• Quantity: 1

Polarizer Holder :

• Standard
• Quantity: 3

Polarizer :

• Ø20 mm with holder
• Quantity: 2

λ/2 Wave Plate :

• Ø10 mm, λ = 632.8 nm, Quartz
• Quantity: 1

λ/4 Wave Plate :

• Ø10 mm, λ = 632.8 nm, Quartz
• Quantity: 1

Lens :

• Focal Length 150 mm
• Quantity: 1

Black Glass Sheet :

• Standard
• Quantity: 1

Beam Expander :

• Focal Length 4.5 mm
• Quantity: 1

He-Ne Laser :

• 1.0 mW @ 632.8 nm

• Quantity: 1

Laser Holder :

• Standard
• Quantity: 1

Optical Current Amplifier :

• Standard
• Quantity: 1
