Experimental System of Pulsed NMR Advanced Physics Experiment

This Pulsed Nuclear Magnetic Resonance (PNMR) experiment system is designed to study the principles of nuclear magnetic resonance using pulse excitation techniques. It enables students to investigate spin echo (SE), free induction decay (FID), spin-lattice relaxation (T₁), spin-spin relaxation (T₂), chemical shift, and the effects of magnetic field homogeneity and paramagnetic ions on nuclear relaxation. The system provides a comprehensive platform for advanced NMR experiments in physics laboratories. Manufactured by Atico Export India.

Experiments :

• Study the Basic Theory and Experimental Configuration of a Pulsed NMR System and Explain NMR Phenomena Using the Classical Vector Model.
• Measure Spin-Spin Relaxation Time (T₂) Using Spin Echo (SE) and Free Induction Decay (FID), and Analyze the Effect of Magnetic Field Homogeneity.
• Measure Spin-Lattice Relaxation Time (T₁) Using the Inversion Recovery Method.
• Study the Relaxation Mechanism and Observe the Effect of Paramagnetic Ions on Nuclear Relaxation Time.
• Measure the T₂ Relaxation Time of Copper Sulfate Solutions at Different Concentrations and Analyze the Relationship Between T₂ and Concentration.
• Measure the Relative Chemical Shift of the Sample.

Modulation Field Power Supply :

• Maximum current: 0.5 A
• Voltage: 0–6.00 V

Homogeneous Field Power Supply :

• Maximum current: 0.5 A
• Voltage: 0–6.00 V

Oscillator Frequency :

• 20 MHz

Magnetic Field Strength :

• 0.470 T

Magnetic Pole Diameter :

• 100 mm

Magnetic Pole Spacing :

• 20 mm

Magnetic Field Homogeneity :

• 20 ppm (10 × 10 × 10 mm measurement volume)

Controlled Temperature :

• 36.500 °C

Magnetic Field Stability :

• Stable after 4 hours warm-up
• Larmor frequency drift less than 5 Hz/min

Standard Accessories :

• Constant Temperature Unit – 1
  • Includes magnet and temperature control device
• RF Transmitting Unit – 1
  • Includes modulation field power supply
• Signal Receiving Unit – 1
  • Includes homogeneous field power supply and temperature display
• Power Cord – 1
  • Standard
• Connection Cables – 12
  • Standard
• Sample Tubes – 10
  • Standard
• Instruction Manual – 1
  • Included
